Product Name Deviser EM9N/EM9D Broadband Electromagnetic Field Meter
Product Code EM9N/EM9D
Deviser EM9N/EM9D Broadband Electromagnetic Field Meter is The EM9N/EM9D Broadband Electromagnetic Field Meter is a high-precision electromagnetic radiation multi-function measuring instrument. It is a high-end electromagnetic field strength meter independently developed by Deviser. It is used to evaluate various electromagnetic environments and human safety environments to comply with safety standards.
Applications:
● Environmental protection
● 5G base station electromagnetic radiation safety detection
● Measuring and monitoring field strengths around broadcasting and radar equipment
● Measuring field strengths to comply with general safety regulations
● Measuring field strengths of cell phone transmitters to demonstrate compliance with human safety standard limit values
● Measuring and monitoring field strength of aeronautical, airport, marine and railway systems
Frequency range: DC ～ 40GHz
Electric field Measurement range: 0.001V/m ～ 999V/m
Magnetic field Measurement range: 0.001μT ～ 99.00mT
Display: 6.53 inches capacitive touchscreen
Resolution: 2400*1080 px.
GNSS: Built in GPS/Beidou and electronics compass
Interface: USB3.0, fiber optics(optional), type-C
Measurement range: ≥ 50 meters
Demodulations: 5G/4G Base Station Demodulations
Measurement: Electric and magnetic field strengths measurement with isotropic probes
Wireless communication: Bluetooth and WiFi
Navigation: Support third-party navigation apps
Operation temperature: -10℃~40℃
Operation time: ≥15 hours / Li-ion battery 4.2v/8000mAH
Power supply: AC90~240V (AC Adapter)
Weight: < 1kg (mainframe + probe)
Dimensions: (LxWxH) 500mm x 100mm x 55mm
• Monitoring efficiency increased to 200% compared to traditional methods
• Quick test for antenna distance and antenna height
• Built in GPS and elect ronics compass
• Site condition easy record with built-in HD camera
• Record working routine and geographic information
• Access base station ID with built-in 5G SIM card
• Auto-generate of drive test data
• User defined test template
• Optional BT and fiber optics
• Operation time ≥ 15 hours
EM9N/EM9D Mainframe: Standard
Portable Carry Case: Standard
Power Adapter: Standard
Type-C Cable: Standard
Laser Rangefinder. Standard
Tripod: Optional
| Document Name | Date | İndirme | Boyut | View |
|---|---|---|---|---|
| Deviser EM9N/EM9D Broadband Electromagnetic Field Meter | 22/03/2022 17:14:48 | 1260 | 1,31 MB | View |
