Product Name EXFO FTB-730C
Product Code FTB-730
+ -
Pcs

The FTB-730C is a preferred OTDR for accurately testing between splitters in fiber optic networks and for analyzing FTTH connections to the smallest details.

  • 1310, 1550, 1625, 1650 nm Wavelengths
  • 39/38/39/39 dB Dynamic Range
  • 2.5 m Attenuation dead zone
  • 30 m PON dead zone
  • 0.1 to 400 km Distance Range
  • 3 to 20,000 ns Pulse Width

Input Power Range:

  • 1490 nm: -65 to 18 dBm
  • 1550 nm: –50 to 28 dBm
Document Name Date İndirme Boyut View
EXFO - FTB730C OTDR 02/10/2019 11:26:10 395 1,2 MB View
