MCX Gen2 AV over IP Decoder

NEW
Product Name MCX Gen2 AV over IP Decoder
Product Code MCX G2

MCX Gen2 Decoders extend and switch video, audio, RS-232, and USB 2.0 signals, or display all of your sources via built-in video wall management. Ideal for point-to-point secure video conferencing, hotel or convention center displays, multi-monitor broadcasts, distributed video matrix or video wall systems, and remote KVM system control, the encoders/decoders comply with TAA specifications.

  • HDMI connectivity, 10-Gbps Ethernet, and analog audio
  • IP switchable with zero latency (requires optional MCX Gen2 Controller)
  • Ultra-light compression, lossless for most content
  • Extension up to 30 km over fiber (maximum distance depends on the SFP+ module and type of fiber used)
  • AV, IR, RS-232, and USB 2.0 extension
  • Basic configuration via front-panel buttons with an OSD

General:

  • Analog Audio: L/R unbalanced
  • Digital Audio: SPDIF, 8-Channels Max
  • Operating Humidity: 20-90% RH(Non- condensing)
  • Power Consumption: Copper - 14.3 W ; Fiber- 18.51W
  • Storage Temperature: -4˚F – 140˚F (-20˚C – 60˚C)
  • Easy Set-up - easy management
  • Uncompressed 4K 60 Hz 4:4:4 Video
  • Create ergonomic worklows for operators
  • Choose copper or fiber version to suit your application
  • Zero Latency
  • HDMI and USB-C encoding and decoding
  • Local video out
  • works with MCX Gen2 controller
Document Name Date İndirme Boyut View
02/12/2022 10:24:13 278 675,83 KB View
